CX-1000 Series: A Smarter Way to Connect, Communicate, and Respond
In today’s fast-moving, security-conscious world, isolated communication systems no longer suffice. Facility managers, safety officers, and operational leads need real-time situational awareness and rapid response capabilities across every square meter of their facilities.
TOA CX-1000 Series bridges the gap between traditional Public Address (PA) systems, IP intercoms, and security infrastructure. Engineered as a unified IP communication ecosystem, it blends voice, video, and control into a single platform designed for seamless scalability and operational clarity.
Why Modern Facilities Require Integrated IP Communication
Traditional PA installations excel at one-way broadcasting, but modern operations demand interactive two-way communication and visual verification.
- Siloed Systems Lead to Delays: Operating PA, CCTV, and door entry systems on separate platforms create operational friction during routine tasks and critical emergencies.
- Visual Verification Matters: Hearing a call or receiving a trigger is good, but seeing what is happening before broadcasting or unlocking a door enables precise decision-making.
- Scalability Across Network Boundaries: Growth should not require replacing core hardware. Modern facilities need platforms capable of expanding effortlessly over LAN/WAN architectures.
Key Integration Pillars of the CX-1000 Series
The CX-1000 Series connects audio and visual security systems through open network standards:
CX-SM1000 System Manager
|
+-------------------------------+-----------------------------------+
| | |
SIP Protocol ONVIF / Video Control I/O
Intercom & VoIP CCTV & Camera Trigger & Alarm
1. Direct SIP Protocol Integration
The system supports standard SIP protocols, enabling smooth communication between CX terminals, IP door stations, and third-party VoIP phone networks. Operators can initiate announcements or field calls directly from an existing PBX handset.
2. ONVIF Camera & CCTV Integration
With ONVIF support, CX video terminals and video door call stations stream live HD video feeds alongside real-time voice calls. Control room operators can visually confirm a situation before broadcasting a message or dispatching security personnel.
3. Comprehensive Control I/O & Legacy Audio Support
Using the CX-CC1016 Control I/O Unit and CX-AF1062 Audio Interface, the CX-1000 Series integrates with external sensors, panic buttons, fire alarm panels, and traditional analog audio gear.
CX-1000 series Lineup Overview
|
Model |
Device Type |
Core Capability & Key Features |
|
System Manager |
Central intelligence manages up to 3,000 devices via web browser interface. |
|
|
Remote Microphone |
Paging console featuring a 5-inch color LCD touchscreen for zone selection. |
|
|
Video Operation Station |
Advanced desktop station with 5-inch touch panel, HD camera, and CCTV integration. |
|
|
Operation Station |
Versatile desktop terminal for daily intercom, speed dialing, and zone paging. |
|
|
Video Call Station |
Outdoor-ready (IP65/IK08) video door station with HD camera and dual mic. |
|
|
Call Station |
Heavy-duty (IP65/IK08) audio door station with dual mic for noise-suppressed clarity. |
|
|
Audio Interface |
Provides 6 analog inputs and 2 outputs for connecting external BGM and legacy hardware. |
|
|
Power Amplifiers |
120W and 240W IP amplifiers featuring 10 x 100V zone speaker outputs. |
|
|
Control I/O Unit |
Equipped with 16 control inputs and 16 outputs for triggering external event scenarios. |
Real-World Applications
- Smart Campuses & Schools: Automate bell schedules via web manager while giving administrative staff immediate touch-screen access for campus-wide emergency overrides.
- Industrial & Logistics Hubs: Combine high-noise horn coverage with rugged door call stations at access gates, letting security verify deliveries visually before granting access.
- Healthcare Facilities: Coordinate staff announcements, manage restricted door entry, and initiate emergency broadcasts from centralized nurse stations.
- Transport Terminals: Manage multi-zone passenger announcements and route passenger assistance calls directly to control rooms.
Future-Proof Your Facility Communication
The CX-1000 Series combines open-standard IP communication, by integrating public address, intercom, and video into a single network topology, facilities gain a scalable foundation built to adapt to evolving operational demands.
For system design support or configuration inquiries, contact TOA Electronics Pte Ltd or visit our Resource Center to download full product catalogues.
If you need assistance selecting the right speaker or system configuration, contact us or our authorized partners for professional guidance.
